VeriFone V200c User Manual

SYSTEM MODE
System Mode Menus
30 V200C REFERENCE GUIDE
To perform a diagnostic procedure on the buzzer,
select Buzzer.
To perform a diagnostic procedure on the printer, insert
paper roll into the unit and then select Printer. A test
receipt is printed and then the unit displays "
PRINTER
TEST HAS FINISHED SUCCESSFULLY
". Press enter to
go back to the Diagnostics menu.
To perform a diagnostic procedure on the keypad LED
lights, select LED.
Home > Manufacturing
To load MIB, select Manufacturing panel.
Table 4 System Mode Submenus (continued)
Display Action
Load MIB
Manufacturing

VeriFone V200c Specifications

General

Memory	64MB SDRAM
Touchscreen	Capacitive
Connectivity	Ethernet, RS-232, USB
Operating System	Verix
Card Readers	Triple track MSR, EMV smart card reader, Contactless NFC
Power Supply	AC input 100-240V, DC output 5V
Operating Temperature	0°C to 40°C
Certifications	EMV Level 1 and 2, PCI
