V660P INSTALLATION GUIDE 13
CHAPTER 2
Device Setup
This chapter describes the device setup procedure. You will learn about:
• Device Location
• Inside the Shipping Carton
• Device Features
• SAM Card
• Examining Connection Port
• Using the Battery
• Connecting the Terminal Power Pack
• Loading a Paper Roll in Device
• Charging the Battery
• Using the Smart Card Reader
• Using the Magnetic Card Reader
• CTLS Transaction
• Wi-Fi/BT Support
Device Location
The following are the guidelines used to select an ideal location for the device.
Environmental
Factors
• Select a flat support surface, such as a countertop or table, place the device.
Please store your V660p-1 device in dry area:
• Operation temperature is 0 to 45° Celsius (32° F to 113° F).
• Storage temperature is -20 to 60° Celsius (-4° F to 140° F).
• Select a location convenient for both the merchant and the cardholder.
• Select a flat support surface, such as a countertop or table, place the device.
• Keep the device away from direct sunlight and anything that radiates heat,
such as a stove or motor.
• Do not use the device where there is high heat, dust, humidity, moisture, or
caustic chemicals or oils.
The device is not waterproof or dustproof and is intended for indoor use only. Any
damage to the unit from exposure to rain or dust may void any warranty.
