DEVICE SETUP
SAM Card
16 V660P INSTALLATION GUIDE
• A magnetic card reader built into the device for performing debit or credit card
transactions. The card can be swiped from either direction. To ensure a proper
read of the magnetic swipe card, insert the magnetic card from the side of the
device as shown in
Figure 12.
• Contactless Reader and EMV have dedicated LEDs lower to the left of the
display for contactless payments. For directions on how to conduct contactless
transactions, see
CTLS Transaction.
• A 3.5 mm audio jack to facilitate accessibility for the visually impaired.
SAM Card
When you first receive your V660p-1, you may need to install one or more SAM
cards, or you may need to replace old cards. You may need to install one or two
Multiple Security Access Module cards or replace an old one.
Installing or
Replacing SAM Card
To install or replace SAM cards:
1 Power off the device.
2 Place the device face down on a soft and clean surface.
3 Remove the back cover of the unit.
Figure 3 Removing Back Cover
Observe standard precautions when handling electrostatically sensitive devices.
Electrostatic discharges can damage this equipment. Verifone recommends
using a grounded anti-static wrist strap.
