DEVICE SETUP
Using the Smart Card Reader
V660
P INSTALLATION GUIDE 23
Using the Smart
Card Reader
Insert the smart card to proceed with the EMV transaction. EMV supports credit
card and debit card transactions.
To Conduct a Smart
Card Transaction
1 Position the smart card with the contacts facing upward (see Figure 11).
2 Insert the card into the reader slot in a smooth, continuous motion until it seats
firmly.
3 Wait for the application to indicate a completed transaction before removing
the card. Premature card removal invalidates the transaction.
Figure 11 Inserting a Smart Card
Using the
Magnetic Card
Reader
Use the magnetic stripe reader to perform credit and debit card transactions.
Using a Magnetic
Card Reader - Debit
or Credit Card
Transaction
1 Position the card with the magnetic stripe facing inwards.
2 To ensure a proper read of the magnetic swipe card, insert the magnetic card
from the side of the device, as shown in the illustration below.
Figure 12 Using Magnetic Stripe Card
3 Swipe the card through the magnetic card reader.
