Vertiv Geist GU2 Series User Manual

SERIAL NUMBER FRAMEDEF
YYYY-MM-DD-
HH-MM-SS
IP ADD
Products unique serial number. This is the
same serial number present on the units
label.
Part of the VLC con-
figuration data and used for
debugging.
Timestamp of
when the scan
occurred.
The IPv4 address of the unit. Locally
Metered units will show Null IP
address.
Table C.1 rPDU Configuration Data
VOLTS AMPS WATTS VA KWH
1 volt 1 amp 1 watt 1 va 1 kwh
Input Phase for Single Phase units. Phase A or Phase AB if 3 Phase
Phase
Amperes
Phase Real
Power
Phase
Apparent
Power
Phase
Kilowatt-
Hours
2 volts 2 amps 2 watts 2 va 2 kwh
Phase B or Phase BC if 3 Phase
Phase
Amperes
Phase Real
Power
Phase
Apparent
Power
Phase
Kilowatt-
Hours
3 volts 3 amps 3 watts 3 va 3 kwh
Phase C or Phase AC if 3 Phase
Phase
Amperes
Phase Real
Power
Phase
Apparent
Power
Phase
Kilowatt-
Hours
4 volts 4 amps 4 watts 4 va 4 kwh
Secondary Input Phase for Single Phase units. Phase A or Phase
AB if 3 Phase
Phase
Amperes
Phase Real
Power
Phase
Apparent
Power
Phase
Kilowatt-
Hours
5 volts 5 amps 5 watts 5 va 5 kwh
Secondary Phase B or Phase BC if 3 Phase
Phase
Amperes
Phase Real
Power
Phase
Apparent
Power
Phase
Kilowatt-
Hours
6 volts 6 amps 6 watts 6 va 6 kwh
Secondary Phase C or Phase AC if 3 Phase
Phase
Amperes
Phase Real
Power
Phase
Apparent
Power
Phase
Kilowatt-
Hours
Table C.2 Power Data
NOTE: Some GU models have Dual Inputs with Monitoring or Dual Inline Monitoring, these units can
have up to three additional Power readings.
BREAKER 1 BREAKER 2 BREAKER 3 BREAKER 4 BREAKER 5 BREAKER 6
Breaker / Circuit 1
Amps
Breaker / Circuit 2
Amps
Breaker / Circuit 3
Amps
Breaker / Circuit 4
Amps
Breaker / Circuit 5
Amps
Breaker / Circuit 6
Amps
Table C.3 Breakers/Circuits
71

Vertiv Geist GU2 Series Specifications
