PLENUM DIMENSIONAL DATA
LIEBERT CW
DOWNFLOW MODELS CW106 - CW114 W/ EC FANS
C
D
H
B
1"
25mm
1"
25mm
1"
25mm
2"
51mm
C
D
2"
51mm
Flange must be specified
on Downflow Models.
A
2"
51mm
1"
25mm
Plenum Height in. (mm)
H
20 (508)
22-3/4 (578)
34-3/4 (883)
A B C D
122 (3099) 34 (864) 118 (2997) 32 (813)
Plenum Dimensional Data in. (mm)
