3. Attachthe plaintop panel and the top panel withholes totop of the plenum assembly using 39sheet-metal
screws, Figure 7.28 below.
Figure 7.28 Front-discharge top-panel attachment
Item Description
1 Toppanel (withholes)
2 Toppanel (plain)
Vertiv | Liebert® CW™Installer/User Guide
72
