Figure 5.1 Correct and Incorrect gravity drains for downflow and upflow units
Item Description
1 Fordownflowunits
2 Forupflowunits
3 Correct draininstallation
4 Incorrect draininstallation
5 Internal drain
6 External drain
Table 5.3 Gravity-fed Drain Line Figure Descriptions
