Item Description Quantity
6 RearPanel (solidorgrilled) 1
7 Short RearPanel (solidor grilled) 1
8 AngleTopRear 1
9 Channel Panel 1 or2
10 TopFrame Extension 1
11 Panel MountingBracket (double panel) 1
12 Channel Frame 1 or2
13 TopFrameAngleBrace 1
14 Panel MountingBracket (singlepanel) 1
15 TopFrame 1
16 Plenum Brace 1
Not shown Washer 1/4 varies
Not shown Bolt1/4-20x 1 varies
Not shown Sheet Metal Screw#8-18x 1/2 varies
Not shown Insulation/Gasket tape varies
Table 7.3 Plenum Parts and Quantities (con-
tinued)
