Specifications26
Table 6-1 UPS Specifications (continued)
CAPACITY 1000 VA/ 900 W 1500 VA/ 1350 W 2000 VA/ 1800 W 3000 VA/ 2700 W
GXTRT- 1000IRT2UXL 1500IRT2UXL 2000IRT2UXL 3000IRT2UXL
BATTERY
Battery Type Valve-regulated, non-spillable, lead acid
Quantity x
Voltage x Rating
2 x 12V x 9Ah 3 x 12V x 9Ah 4 x 12V x 9Ah 6 x 12V x 9Ah
Recharge Time 4 hours recover to 90% capacity (Typical)
Charging
Current
1.0 A (max.)
Charging
Voltage
27. 2 VDC ± 1% 40.9 VDC ± 1% 54.4 VDC ± 1% 81.7 VDC ± 1%
PHYSICAL
Unit Dimensions
D X W X H (mm)
312 x 438 x 88 462 x 438 x 88 632 x 438 x 88
Unit Weight
(kgs)
11 14.5 18.2 27.6
Shipping
Dimensions D X
W X H (mm)
600 x 500 x 240 700 x 565 x 240 760 x 600 x 240
Shipping Weight
(kgs)
13.1 16.8 20.7 31.2
MANAGEMENT
Smart RS-232 or
USB
Supports Windows® 2003/XP/Vista/2008/7/8/2012/10/2016/2019, Linux, and MAC
Optional SNMP Power management from SNMP manager and web browser
AGENCY
Safety CE Mark; IEC/EN 62040-1: 2014
EMI IEC/EN 62040-2:2006+AC:2006 Class A
Surge Immunity EN 61000-4-5: 2005 Class 2 L-N, Class 3 L-G
Transportation ISTA 2A
ENVIRONMENTAL REQUIREMENTS
Operating
Temperature, °C
0 to 50*
Storage
Temperature, °C
-20 to 50
Operating
Relative
Humidity
20% to 90%, non-condensing
Storage Relative
Humidity
10% to 90%, non-condensing
Operating
Elevation
2000 m without derating. Between 2000 and 3000 m, derate 1% for every 100m.
Operation above 3000 m is not supported.
Noise Level 55 dBA Max @ 1 Meter
*To extend battery life, it is recommended to use the UPS in the range of 15 - 25 °C.
The threshold of low line transfer and low line comeback is increased when Ambient Temp. is 35 - 50 °C.
70% derating of output when Ambient Temp. is 40 - 50 °C.
The overload capacity is decreased when Ambient Temp. is 40 - 50 °C.
Transfer to bypass mode and show temp. alarm when Ambient Temp. > 50 °C and transfer back to online mode when Ambient Temp. < 40 °C.
