Vertiv | Liebert® GXT RT+ | Installer/User Guide 27
Table 6-2 EBC Specifications
MODEL NUMBER GXTRT- EBC24VRT2U EBC36VRT2U EBC48VRT2U EBC72VRT2U
USED W/UPS MODEL GXTRT- 1000IRT2UXL 1500IRT2UXL 2000IRT2UXL 3000IRT2UXL
PHYSICAL
Unit Dimensions D X W X H (mm) 410 x 438 x 88 510 x 438 x 88 630 x 438 x 88
Unit Weight (kgs) 12.5 17.2 23.3 41.5
Shipping Dimensions D X W X H (mm) 600 x 500 x 240 700 x 565 x 240 760 x 600 x 240
Shipping Weight (kgs) 15 22 28.5 48.5
BATTERY
Battery Type Valve-regulated, non-spillable, lead acid
Battery Configuration
Two parallel strings of two
12V/9Ah
batteries in series.
Two parallel strings of
three 12V/9Ah
batteries in series.
Two parallel strings of
four 12V/9Ah
batteries in series.
Two parallel strings of six
12V/9Ah
batteries in series.
Charging Voltage 27.2 VDC ± 1% 40.9 VDC ± 1% 54.4 VDC ± 1% 81.7 VDC ± 1%
AGENCY
Safety CE Mark; IEC/EN 62040-1: 2014
EMI IEC/EN 62040-2: 2006+AC:2006 Class A
Surge Immunity EN 61000-4-5: 2005 Class 2 L-N, Class 3 L-G
Transportation ISTA 2A
ENVIRONMENTAL REQUIREMENTS
Operating Temperature, °C 0 to 50
Storage Temperature, °C -20 to 50
Operating Relative Humidity 20% to 90%, non-condensing
Storage Relative Humidity 10% to 90%, non-condensing
Operating Elevation
2000 m without derating. Between 2000 and 3000 m, derate 1% for every 100 m.
Operation above 3000 m is not supported.
Table 6-3 GXTRT-1000IRT2UXL Runtime Table
See Note 1
LOAD
INTERNAL
BATTERY
ONLY
NUMBER OF EXTERNAL BATTERY CABINETS
1 2 3 4 5 6
% VA W Minutes
25 250 225 19 69 129 184 240 291 335
50 500 450 9 38 70 103 139 176 213
69 690 621 5.3 26 48 72 95 120 145
75 750 675 5 10 10 10 10 10 10
80 800 720 3.5 3.5 3.5 3.5 3.5 3.5 3.5
90 900 810 3.5 3.5 3.5 3.5 3.5 3.5 3.5
100 1000 900 3.1 3.5 3.5 3.5 3.5 3.5 3.5
