Vertiv LIEBERT GXT5 Series User Manual

GXT5 Description4
Table 1-1 UPS Models and Power Ratings
MODEL NUMBER NOMINAL POWER RATING
GXT5-5000IRT5UXLN*
5 kVA/5 kWGXT5-5000IRT5UXLE
GXT5-5000HVRT5UXLN*
GXT5-6000IRT5UXLN*
6 kVA/6 kW
GXT5-6000IRT5UXLE
GXT5-8000IRT5UXLN*
8 kVA/8 kWGXT5-8000IRT5UXLE
GXT5-8000HVRT5UXLN*
GXT5-10KIRT5UXLN*
10 kVA/10 kWGXT5-10KIRT5UXLE
GXT5-10KHVRT5UXLN*
GXT5-16KIRT9UXLN*
16 kVA/16 kW
GXT5-16KIRT9UXLE
GXT5-20KIRT9UXLN*
20 kVA/20 kW
GXT5-20KIRT9UXLE
*Only these models are available in the ASIA PACIFIC region.
1.2. Front Panels
The various GXT5 models have the same general appearance, with the main dierence being the receptacle
types on the rear panel. Figure 1-1 below, shows the 5-kVA to 10-kVA model in a tower and a rack conguration.
When mounted in a rack, the 5- to 10-kVA units are turned 90 degrees. The orientation of the 16-kVA to 20-kVA
models is the same in a rack or tower conguration.
Figure 1-1 Front View
ITEM DESCRIPTION
1 Operation/Display panel
2 Upper bezel
3 Lower bezel/battery-access door

Vertiv LIEBERT GXT5 Series Specifications

General

Model	LIEBERT GXT5 Series
Product Type	UPS
Topology	Double Conversion Online
Display	LCD
Form Factor	Tower, Rackmount
Output Voltage	200/208/220/230/240 VAC
Output Frequency	50/60Hz ±0.1Hz (battery mode)
Typical Backup Time	Varies by model and load
Communication Ports	USB, RS-232
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Certifications	UL, cUL, CE, RoHS
Battery Type	Valve Regulated Lead Acid (VRLA)
