Vertiv | Liebert® GXT5™ | Installer/User Guide 11
Figure 1-8 PD5-CE6HDWRMBSU for GXT5-5000HVRT5UXLN
ITEM. DESCRIPTION
1 POD Panel view (on rear of unit)
2 POD inner-surface view
3 Quick connect
Figure 1-9 PD5-CE10HDWRMBS for GXT5-8000/10KIRT5UXLN (XLE)
ITEM. DESCRIPTION
1 POD Panel view (on rear of unit)
2 POD inner-surface view
3 Quick connect

Vertiv LIEBERT GXT5 Series Specifications

General

Model	LIEBERT GXT5 Series
Product Type	UPS
Topology	Double Conversion Online
Display	LCD
Form Factor	Tower, Rackmount
Output Voltage	200/208/220/230/240 VAC
Output Frequency	50/60Hz ±0.1Hz (battery mode)
Typical Backup Time	Varies by model and load
Communication Ports	USB, RS-232
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Certifications	UL, cUL, CE, RoHS
Battery Type	Valve Regulated Lead Acid (VRLA)
