Vertiv LIEBERT GXT5 Series User Manual

Operation and Display Panel52
4.2.7. About Screen
The About screen oers tabs that list information about the product and the network.
To view the product and network information:
1. At the main menu, select the About icon, and press Enter.
2. Use the arrow buttons to move the cursor left/right and select a tab, then press Enter to display the information
for the selected tab.
Figure 4-8 About Screen Tabs
ITEM DESCRIPTION
1 Screen tabs with Eiciency tab selected
Note: The tab shown in the gure is an example of the graph and does not represent the actual capacity values for your UPS model.
4.3. Editing Display and Operation Settings
You may adjust the display settings and UPS conguration via the LCD. The display and operation settings are
password protected. The default password is 111111 (six ones).
NOTE: We recommend that you change the password to protect your system and equipment and record the new
password and store it in an accessible location for later retrieval. See Changing the Password on the next page.
To enter the password:
1. Press the up-arrow button to change the digit, then press the down-arrow button to move to the next digit.
2. Repeat to select each digit, and press Enter to submit the password.

Vertiv LIEBERT GXT5 Series Specifications

General

Model	LIEBERT GXT5 Series
Product Type	UPS
Topology	Double Conversion Online
Display	LCD
Form Factor	Tower, Rackmount
Output Voltage	200/208/220/230/240 VAC
Output Frequency	50/60Hz ±0.1Hz (battery mode)
Typical Backup Time	Varies by model and load
Communication Ports	USB, RS-232
Operating Temperature	0°C to 40°C (32°F to 104°F)
Relative Humidity	0% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Certifications	UL, cUL, CE, RoHS
Battery Type	Valve Regulated Lead Acid (VRLA)
