Specications72
Table 7-10 Battery Run Time, 6-kVA Models
NO.
OF
EBC S
EBC
AH
NO.
TOTAL
NO. OF
AH
BACKUP TIME (MIN)
6 KVA
5.4 KV
A
4.8 KV
A
4.2 KV
A
3.6 KV
A
3 KVA
2.4 KV
A
1.8 KV
A
1.2 KV
A
0.6 KVA
UPS 0 9 5.5 6.0 7.5 9.0 11.0 14.5 19.5 29.0 48.0 100.0
UPS+1 EBC 9 18 14.5 17.0 20.0 24.0 30.0 38.5 50.5 70.0 107.0 226.0
UPS+ 2 EBC 18 27 26.0 30.5 35.5 42.0 51.0 63.5 81.5 110.0 172.0 357.5
UPS+ 3 EBC 27 36 39.0 44.5 51.5 60.5 72.0 88.0 112.5 154.0 242.0 489.0
UPS+ 4 EBC 36 45 51.5 58.5 67.0 78.0 92.5 113.0 145.0 201.5 312.0 621.0
UPS+ 5 EBC 45 54 64.5 72.5 82.5 96.0 113.5 138.5 181.5 249.5 382.0 752.5
UPS+ 6 EBC 54 63 77.0 86.5 98.5 113.5 134.0 168.0 218.0 297.5 452.0 884.5
Table 7-11 Battery Run Time, 5-kVA Models
NO. OF
EBCS
EBC AH
NO.
TOTAL
NO. OF
AH
BACKUP TIME (MIN)
5KVA 4.5KVA 4KVA 3.5KVA 3KVA 2.5KVA 2KVA 1.5KVA 1KVA 0.5KVA
UPS 0 9 7.0 8.0 9.5 11.5 14.5 18.5 25.0 36.5 59.0 120.0
UPS+1 EBC 9 18 19.0 22.0 26.0 31.0 38.5 48.0 62.5 85.0 129.0 272.5
UPS+2 EBC 18 27 33.5 38.5 45.0 53.0 63.5 78.0 99.0 133.0 211.0 427.5
UPS+3 EBC 27 36 49.0 55.5 64.0 74.0 88.0 107.5 136.0 189.5 294.0 582.5
UPS+4 EBC 36 45 64.0 72.0 82.5 95.5 113.0 138.0 179.5 246.0 377.0 737.5
UPS+5 EBC 45 54 79.0 89.0 101.0 117.0 138.5 173.0 222.5 303.0 460.0 892.5
UPS+6 EBC 54 63 94.0 105.5 120.0 139.0 168.0 208.0 266.0 359.5 543.0 1047.5
NOTE: Up to 10 EBCs can be connected to enhance the runtime but auto-detection function can support only
up to 6 number of EBCs.
