B --- 4 Liebert HPM --- A/W/F/D/H
Tab. 4 --- Electrical data
Component EC FAN
(400V --- 3Ph --- 50 Hz)
COMPRESSOR
(400V --- 3Ph --- 50 Hz)
STANDARD R410A MOTOR
Configuration Model OA
(*)
(A)
FLA
(A)
LRA
(A)
Nominal
power
(kW)
(*)
OA
(**)
FLA LRA Nominal
power
(kW)
(**)
Winding
resistance
(Ohm)
UNDER (U)
OVER (O)
CONSTANT (K,L)
GRILL (G)
S0FxA/W 3,01 3,01 0,10 0,15 7,40 12,80 60,00 1,59, 1,30
S0HxA/W 1,39 2,93 0,10 0,21 3,91 6,50 38,00 2,05 ---
S1AxA/W 1,65 2,93 0,10 0,25 4,58 8,00 43,00 2,87 ---
S1DxA/W 1,97 2,93 0,10 0,30 5,75 10,30 51,50 3,33 ---
S1ExA/W 1,11 4,00 0,10 0,68 5,65 10,30 51,50 3,27 ---
S1GxA/W 1,52 4,00 0,10 0,95 6,89 11,80 64,00 3,79 2,80
S2ExA/W 1,69 4,00 0,10 1,04 10,08 15,00 101,00 5,18 1,80
S2GxU/O 2,21 4,00 0,10 10,84 16,20 101,00 5,55 1,80
M2HxU/O 1,77 4,00 0,10 1,08 10,84 16,20 101,00 5,55 1,80
M3AxA/W 2,32 4,00 0,10 1,44 12,17 21,00 111,00 6,33 1,40
M3FxA/W 2 x 1.04 2x4.0 2x0.1 2 x 0.65 2X6,89 2X11,8 2X64 2X3,795 2x2.8
M3GxA/W 2 x 1.04 2x4.0 2x0.1 2 x 0.65 13,98 22,00 118,00 7,28 1,20
M4ExA/W 2 x 1.58 2x4.0 2x0.1 2 x 0.98 17,44 31,00 140,00 9,28 1,1
M4HxA/W 2 x 1.59 2x4.0 2x0.1 2 x 0.99 2X10,09 2X15 2 x 101 2X5.185 2X1,8
M5BxA/W 2X1,76 2x4.0 2x0.1 2X1,08 22,25 34,00 174,00 11,26 0,80
M5CxA/W 2X2,25 2x4.0 2x0.1 2X1,4 2X10,84 2X16,2 2X101 2X5,545 2X1,8
M5DxA/W 2 x 2.47A 2x4.0 2x0.1 2 x 1.52 2X12,17 2x21 2 x 111 2X6,325 2x1.4
M7LxA/W 2 x 3.13 2x4.0 2x0.1 2 x 1.94 2X13,98 2x22 2 x 118 2X7,257 2X1,2
L8FxA/W 2 x 4.16 2x5.0 2x0.1 2x2.7 2x17,38 2x31 2 x 140 2X9,28 2X1,1
L9HxA/W 2X4,84 2x5.0 2x0.1 2 x3,15 2X22,21 2X34 2X174 2X11,235 2X0,8
UNDER (U)
OVER (O)
S1GxF/D/H 1,15 4,00 0,10 0,71 6,90 11,80 64,00 3,79 2,80
S2ExF/D/H 1,52 4,00 0,10 1,03 10,06 15,00 101,00 5,16 1,80
S2GxF/D/H 2,17 4,00 0,10 1,45 10,85 16,20 101,00 5,55 1,80
M2HxF/D/H 2,27 4,00 0,10 1,42 10,85 16,20 101,00 5,55 1,80
M3FxF/D/H 2 x 1.15 2x4.0 2x0.1 2 x 0.71 2X6,92 2X11,8 2X64 2X3,81 2x2.8
M3GxF/D/H 2 x 1.16 2x4.0 2x0.1 2 x 0.71 13,98 22,00 118,00 7,28 1,20
M4ExF/D/H 2 x 1.73 2x4.0 2x0.1 2X1,06 17,43 31,00 140,00 9,31 2X1,1
M4HxF/D/H 2x2,2 2x4.0 2x0.1 2X1,07 2X10,08 2X15 2 x 101 2X5.18 2X1,8
M5BxF/D/H 2X2,44 2x4.0 2x0.1 2X1,5 22,24 34,00 174,00 11,26 0,80
M5CxF/D/H 2X2,44 2x4.0 2x0.1 2X1,5 2X10,85 2X16,2 2X101 2X5,55 2X1,8
M5DxF/D/H 2 x 2.47 2x4.0 2x0.1 2 x 1.52 2X12,17 2x21 2 x 111 2X6,325 2x1.4
L8FxU 2 x 2,98 2x5.0 2x0.1 2X1,93 2x17,36 2x31 2 x 140 2X9,26 2X1,1
DISPLACEMENT
S0FDA/W 0,52 3,01 0,10 0,07 7,36 12,80 60,00 1,59 1,30
S0HDA/W 0,55 2,93 0,10 0,11 3,92 6,50 38,00 2,07 ---
S1ADA/W 1,40 2,93 0,10 0,21 4,57 8,00 43,00 2,62 ---
S1DDA/W 1,67 2,93 0,10 0,25 5,76 10,30 51,50 3,34 ---
S1EDA/W 0,96 4,00 0,10 0,60 5,66 10,30 51,50 3,28 ---
S1GDA/W 1,02 4,00 0,10 0,64 6,90 11,80 64,00 3,80 2,80
S2EDA/W 1,14 4,00 0,10 0,70 10,07 16,20 101,00 5,55 1,80
S2GxU/O 2,15 4,00 0,10 1,34 10,55 16,00 101,00 5,55 1,80
M2HxU/O 1,19 4,00 0,10 1,08 10,85 16,20 101,00 5,55 1,80
M3ADA/W 1,77 4,00 0,10 1,09 12,17 21,00 111,00 6,33 1,40
(*) At standard operating conditions ESP: 50 Pa for Over units and 20 Pa for Under units. Filters: class G4.
(**)At nominal operating conditions: Condensing temperature 45_C --- Room conditions: 24_C / 50% R.H.
