Vertiv Liebert HPM User Manual

Refrigerant a
nd hydraulic connections
D---9 Liebert HPM --- A/W/F/D/H
English
Fig. 10 --- Chilled water and refrigerant connections Liebert HPM SxxxD, MxxxD and LxxxD
Frontal view
ILOGIFCOFC
Non---return valve
IL
Refrigerant liquid line inlet
OG
Refrigerant gas line outlet
IFC
Water inlet to Freecooling coil
OFC
W a t e r o u t l e t t o D r y --- C o o l e r
Fig. 11 --- Chilled water and refrigerant connections Liebert HPM SxxxF/H, MxxxF/H and LxxxF/H
Frontal view
IWCOWCIFCOFC
IWC
Water to condenser inlet
OWC
Water from condenser outlet
IFC
Water inlet to Freecooling coil
OFC
W a t e r o u t l e t t o D r y --- C o o l e r
