Refrigerant a
nd hydraulic connections
D --- 8Liebert HPM --- A/W/F/D/H
English
Fig. 8 --- Refrigeration connections
Liebert HPM
SxxxA --- MxxxA --- LxxxA
gas line
liquid line
Frontal view
OG IL
Non---return valve
IL
Refrigerant pipe inlet
OG
Refrigerant pipe outlet
Notes: recommended diameters see Table in Chap. 4.
Fig. 9 --- Water connections Liebert HPM SxxxF/H, MxxxF/H and LxxxF/H
Frontal view
OWC IWC
IWC
Water to condenser inlet
OWC
Water from condenser outlet
