distance between the condenser and envelope, “b” and “c” is the distance between two condensers.
• It is recommended to install the No.1 system on the same side (as shown in Figure 2-5 & 2-6) to convenient
installation.
• If condensers cannot move to the installation location at one time as per site situation, it is required to
reserve adequate distance between condensers before second installation.
• The condenser needs suicient installation and service space around the installation place. And the specic
space requirements are shown in Figure 2-8, 2-9 & 2-10 and Table 2-1 & 2-2.
Figure 1-8 Spread evenly installation space required
• In Figure 2-8 the space requirement is based on the area of the building to provide the minimum spacing for air
circulaon within 10 m around the installaon site. If the air circulaon is not sucient, please consult Verv
personnel for technical conrmaon.
