S600D
56
Figure 5-8 Bypass normal interface
In Inverter mode, press and hold the power button. If the bypass is abnormal, then the interface shown in Figure 5-9
will appear, select 'YES' to shut down the UPS output.
Figure 5-9 Bypass abnormal interface
For detailed information about Normal mode, Bypass mode, and Battery and Maintenance Bypass mode, please refer
to 1.4 .
Transfer From Bypass Mode To Inverter Mode
In Bypass mode, press and hold the power button.
If ECO mode is not enabled, the interface shown in Figure 5-10 will appear.
Note
In Bypass mode, the load is directly fed by the mains power instead of the pure AC power from the inverter.
