- Remove the protection, the bracket and the start-

er acting on the screw shown in the figure.

- Remove the 2 screws and the starter support with

the gasket.

- Remove the 4 fixing screws shown in the figure

and the vacuum chamber cover.

WARNING

DURING THE REMOVAL OF THE CARBURETTOR COVER

TAKE SPECIAL CARE NOT TO RELEASE THE SPRING

ACCIDENTALLY.

Engine LXV 125

ENG - 134
