- Remove the vacuum valve together with the di-

aphragm.

- Unscrew the bayonet joint 1/8 of a turn and re-

move, take out the spring and vacuum valve nee-

dle

- Remove the 4 screws indicated in the figure.

- Remove the chamber with the accelerating

pump, its control and gasket.

LXV 125 Engine

ENG - 135
