10 Mechanical trouble shooting
10.1 Service / Trouble shooting
CHECKLIST
STATION :
1) Is the electrode air gap distance set correct?
Check distance is max. 1,5 mm between
electrode and roll face.
2) Is the electrode completely straight?
Check air gap / alignment along the whole
electrode.
3) Is the HP‑cable mounted correctly?
4) Is the EARTH-cable connected?
(Between station and transformer)
5) Is the STATION cable connected?
(Between the iPM200 generator and station)
GENERATOR / HP-TANSFORMER:
1) Is the HP‑cable mounted correctly?
2) Is the HA‑cable connected correctly to
terminal -X18?
(Between the high voltage transformer and
iPM200 generator)
3) Is the MULTI cable mounted correctly to
terminal -X7?
(Between the high voltage transformer and
iPM200 generator)
4) Is the STATION cable connected correctly
to terminal -X5?
(Between the iPM200 generator and station)
5) Is the mains cable supplied and connected
correctly to terminal -X19 and does it carry the correct voltage?
FAN:
1) Check visually that the external fan is rotating the correct way according to the arrow on
the fan (If not, swap two of the phases if not).
