Vetaphone iPM200-5 - System Parameters

iPM 200 generator module
® Vetaphone March 2021 3401201GB
Page 30 of 52
7.3 System parameters
All * menus are protected by a user access code which is 246813
All § menus are protected by a technician access code.
Menu
No.
Title
Description
1
GENERATOR
Menu
1.1
IO SETUP
Submenu
1.1.1*
Input mode
Configure Polarity of inputs (NPN, PNP)
1.1.2*
RC 1 Input
Configure Type of rotation sensor (NPN, PNP, NAMUR)
1.1.3*
RC 1 Min
Configure minimum rotation speed
1.1.4*
RC 1 Max
Configure maximum rotation speed
1.1.5*
RC 1 Mode
Configure Rotation control (0=OFF / 1=ON / 2=AUTO)
1.1.6*
RC 2 INPUT
Configure Type of rotation sensor (NPN, PNP, NAMUR)
1.1.7*
RC 2 Min
Configure minimum rotation speed
1.1.8*
RC 2 Max
Configure maximum rotation speed
1.1.9*
RC 2 Mode
Configure Rotation control (0=OFF / 1=ON / 2=AUTO)
1.2 §
CONTROL MODE
Submenu
1.2.1§
Power Mode
Configure system to run in Power mode (watt) or
in W*min/m2 mode
1.2.2§
Auto Min
Automatic Power Control Min. watt*min/ m2
1.2.3§
Auto Max
Automatic Power Control Max. watt*min/ m2
1.2.4§
Power Min
Min. total output power in kW
1.2.5§
Power Max
Max. total output power in kW
1.2.6§
Error Count
Error counts before alarm
1.2.7§
Error Time
Error time before restart in 1 second
1.2.8§
Err Rst Time
Error time before reset in 1/10 second
1.2.9§
Run Program
1.3
BLOWER
Submenu
1.3.1
Blower Start
Blower start delay in seconds
1.3.2
Blower Stop
Blower stop delay in seconds
1.3.3
Blower Active
Activates blower
