iPM 200 generator module
® Vetaphone March 2021 3401201GB
Page 31 of 52
Menu
No.
Title
Description
1.4§
PULS
Submenu (This menu is locked. Vetaphone technician
access only)
1.4.1§
Puls@Min
Min PWM threshold at minimum Power
1.4.2§
Puls@Max
Max PWM threshold at Maximum Power
1.4.3§
Freq@Min
Max Allowed Frequency at Minimum Power
1.4.4§
Freq@Max
Min Allowed Frequency at Maximum Power
1.4.5§
Feed@Min
Min Allowed Feedback threshold at Minimum Power
1.4.6§
Feed@Max
Max Allowed Feedback threshold at Maximum Power
1.4.7§
Overload
Over current protection threshold
1.4.8§
PID Enable
PID Power regulation
1.4.9§
Peak Enable
Flashover detection
1.5
DATE / TIME
1.5.1
Date
Set date
1.5.2
Time
Set time
1.6
DISPLAY§
1.6.1
User menu en§
Enable custom user menu
1.7
SELF-TEST
1.7.1*
Extern self-test
1.7.2
Reset internal self-test
1.8*
UNIT
1.9
POWER
1.9.1*
Min. DLP
Minimum limit when DLP enabled
1.9.2*
DLP AUTOTUNE
Autotune enable/disable in DLP
1.9.3*
FB Amplitude
Feedback amplitude check enable/disable
1.9.4*
Max Amp faults
Maximum number of amplitude faults
1.9.5*
FB ZeroCross
Feedback ZeroCross check enable/disable
1.9.6*
Max ZC fault
Maximum of missing zero cross
1.9.7*
Gen.. Mode
Generator mode (standalone, master or slave)
2
STATION
Menu
2.1*
Treat width
Treating width in millimetres
2.2*
No. of sides
No. of sides to be treated
2.3*
Hole Pitch
Distance between pitch holes on roller
3
OPTIONS
Menu
3.1
PROFIBUS
Submenu
3.1.1*
Profi Addr
Profibus node address (default 10)
3.1.2*
Profi Length
Select data length 2-byte, 8-byte or 16-byte
(The length is locked to 8-byte)
3.1.3§
Profi Enable
Activate or deactivate the PROFIBUS interface
3.2
CANOPEN
Submenu
3.2.1*
CAN Addr
CANOpen Node id (default 10)
3.2.2*
CAN Baudrate
Select communication speed for the CANBUS interface
3.2.3§
CAN Enable
Activate or deactivate the CANBUS interface
3.2.4*
CAN Auto start
CANbus interface automatically goes to operational
mode. no need for NMT manager
