iPM 200 generator module
® Vetaphone March 2021 3401201GB
Page 32 of 52
3.3
IO
Submenu
3.3.1
Input Mode
Select mode 0-10V or 0-20mA or 2-10V or 4-20mA
3.3.2
Output Mode
Select mode 0-10V or 0-20mA or 2-10V or 4-20mA
3.3.3
IO Enable
Activate or deactivate the IO interface
3.4
Pinhole ctrl
Submenu
3.4.1*
No of pulses
Number of pulses, before a reject signal
3.4.2*
Gain
In- or decrease the amplification of the feedback signal
3.4.3*
SKIP mode
Enable skip mode
3.4.4*
Max pinholes
Limit for allowed pinholes
3.4.5*
FB Chk delay
Delay for feedback check
3.4.6*
FB Chk count
3.5
Modbus
3.5.1§
Enable Modbus
Enables the Modbus interface
(Note, it’s not possible to run with both an TF415 and the Modbus
interface at the same time)
3.5.2*
Modbus Address
Sets the Modbus slave address (1-127)
(Note, has to be set prior to enabling the interface)
3.5.3*
Modbus Baud rate
Sets the Modbus baud rate,
(Note, has to be set prior to enabling the interface)
3.5.4*
Modbus Parity
Sets the Modbus parity mode,
(Note, has to be set prior to enabling the interface)
3.5.5*
Modbus PollTime
Set the timeout time.
(Note, has to be set prior to enabling the interface)
3.5.6*
Modbus Dev type
Set which device is connected.
(Note, has to be set prior to enabling the interface)
3.6
UNITS
3.6.1
Unit 1 type
Unit 1 type
3.6.2
Unit 1 tddr
Unit 1 address
3.6.3
Unit 2 type
Unit 2 type
3.6.4
Unit 2 tddr
Unit 2 address
3.6.5
Unit 3 type
Unit 3 type
3.6.6
Unit 3 tddr
Unit 3 address
3.6.7
Unit 4 type
Unit 4 type
3.6.8
Unit 4 tddr
Unit 4 address
3.9*
POWER
Submenu
3.9.1*
DPC Level
DPC power mode. 0 = Max., 1-3 < stepwise power
3.9.2*
DLP Mode
Dynamic Low Power mode selection
3.9.3*
DLP Level
Dynamic Low Power Level, meaning of this parameter
depends DLP mode
3.9.4*
DLP threshold
DLP threshold in watt, DLP function activates when
requested power are below this level
3.9.5*
Feedback chk
Turns on or off check for transformer Feedback.
3.9.6§
Autotune
Enable autotune
3.9.7*
Freq. devia.
Allowed frequency deviation
3.9.8*
Phase corr.
Phase correction for Autotune
3.9.9*
NAL delay
Delay for Level alarm checking
4
USB
Menu
4.1
Disconn USB?
Disconnection of USB-stick
(Note: Menu 4 has been removed from firmware version 5.20)
5
VERSION
Menu
5.1
SOFTWARE
Submenu
5.1.1
Customer SW
Customer software version
5.1.2
PWM SW
PWM software version
5.1.3
PU SW
PU software version
