6.1.2. Menu Page and Functions of the Buttons
MENU DESCRIPTION L BUTTON MIDDLE
BUTTON
R BUTTON
Parameter User parameters Scroll Select Exit
Congure Conguration parameters Scroll Select Exit
Diagnostic Diagnostic values Scroll Select Exit
6.1.3. Parameters Setting
User parameters and functions of the buttons
NUMBER DESCRIPTION DEFAULT
VALUE
L BUTTON MIDDLE
BUTTON
R BUTTON
P-01 Temperature unit of measure ºC Scroll Select Change
P-02 Auto start (after switching on) No Scroll Select Exit
P-03 Contrast 5 Scroll Select Exit
P-04 Beep on/off Yes Scroll Select Change
P-05 Manual alarm reset No Scroll Select Change
6.1.4. Congure Parameters
A password is required to enter this menu.
CAUTION: all these parameters are correctly set in the factory: no changes should
be made by the user.
6.1.5. Diagnostic Parameters
DESCRIPTION UNIT OF MEASURE
Cell temperature ºC
Radiator temperature ºC
Water resistance kΩ
Power %
Cell voltage Volt
