4. THE UNIT
4.1 Front and Rear Panel
The front and the rear panel have grids to dissipate the heat generated in the unit. Two fans force the air
movement. These grids must be free to guarantee the instrument specications.
The front panel features the LCD display with keypad. Three buttons are used to access the various functions
and change the set parameters.
The rear panel features connection to the main power supply with 115V/230V voltage selector, the USB
connection for remote control, connection to the “Water Fill” inlet and outlet connections.
4.2 Specications
PCB 1500W PCB 1500 PLUS PCB 1500 HP
Operating temp
o
C (
o
F) 20 to 60 (68 to 140) 0 to 110 (32 to 230) 4 to 90 (39 to 194)
Temperature Accuracy
o
C (
o
F) +/- 0.2 (0.36)
Temperature Precision +/- 0.1 (0.18)
Managing Peltier Cell Directly No Yes No
Interface RS-232 or USB
Display Digital
LED indicators Power on/off, errors
Electrical supply 220-240V 50-60Hz / 110-120V 50-60Hz
Power consumption (watts) 160
Dimensions mm (in) 240W x 255H x 520D (9.5W x 10H x 20.5D)
Weight kg (lb) 10 (22) 15 (33)
Shipping dimensions mm (in) 330W x 390H x 595D (13W x 15.4H x 23.4D)
Shipping weight kg (lb) 14 (31) 19 (42)
Inlet connection Rapid water tting PMCD female 1/8”
Outlet connection Rapid water tting PMCD female 1/8”
Certication CE, cMETus (UL and CSA compliant)
MODELS & SPECS
