Vicon Extra 328 - Page 31

Assembly - attachment
31
540 rpm
If the machine is to be fitted to a tractor's PTO shaft running at 540
rpm, the following procedure must be followed:
 Remove both PTO shafts from the transmission.
 Remove both guards from the transmission.
 Remove the guard.
 Remove the tool box.
 Remove the bolts.
Guard
Guard
Tool box
Bolts
