Assembly - attachment
32
Turn the transmission.
• The transmission is turned so that the two shafts on the
transmission swap places.
Fit the bracket.
All bolts must be tightened to the torque shown.
Do not forget the Nord-Lock discs.
Fit both guards on the transmission.
The holes in the guard for lubricating the PTO shaft must be
accessible.
Fit both PTO shafts.
Fit the tool box.
Fit the guard.
