Maintenance
151
Transmission
As required
 »Maintenance intervals« page 79
The V-belts are changed in the following way:
 Activate the tractor hydraulics and lower the cutting unit of the
machine.
 Dismantle the guard.
 Completely loosen the bolt on the spring.
 Remove the V-belts.
 Mount the new V-belts.
Bolt
Bolt
V-belt
