Preparation
33
Mount the transmission.
Do not forget the lock plate.
Fit the bolts on both sides of the transmission
Tighten all bolts to a torque of 225 Nm (165 ft/lb).
Fit the adapter.
Fit the console.
Fit the bolts on both sides of the transmission.
Tighten all bolts to a torque of 225 Nm (165 ft/lb).
Force the corners of the lock plate back in against all the bolt
heads.
Mount the P.T.O shaft.
Bolt
Adapter
Lock plate
225 Nm
165 ft/lb
Bolt
Bracket
225 Nm
165 ft/lb
