Vicon SVFT-C22 - Page 39

CO
NNE
C
T
O
R
/
PIN
NUMBER
CONNECTOR TYPE CONNECTOR/PIN LABEL SIGNAL NAME
BNC (female)
VIDEO (J1)
J1
VIDEO
Video output
AMP Heade
r
J2
J2 (Fiber Optic board)* Video/RS-422 data
TERMINAL BLOCK
POWER (TB1)
TB1-1
H
Hot
TB1-2
N
Neutral
TERMINAL BLOCK
A
LARM (TB2)
TB2-1
ALARM 1
Alarm input 1
TB2-2
GND
Ground
TB2-3
ALARM 2
Alarm input 2
TB2-4
GND
Ground
TB2-5
ALARM 3
Alarm input 3
TB2-6
GND
Ground
TB2-7
ALARM 4
Alarm input 4
TB2-8
GND
Ground
TERMINAL BLOCK
COMM/RELAY (TB3)
TB3-1
COMM IN +
Command in +
TB3-2
COMM IN -
Command in -
TB3-3
RESP OUT +
Response out +
TB3-4
RESP OUT -
Response out -
TB3-5
GND
Ground
TB3-6
RELAY C
Relay, common
TB3-7
RELAY NO
Relay, normally open
TB3-8
RELAY NC
Relay, normally closed
*J2 connection provided to accommodate optional fiber optics interface board that provides video and
RS-422 full duplex data through a standard fiber optics connector.
Table 2A
Wiring Connections – Standard Coaxial/Fiber Optic Versions
XX134-01-00 Rev 205 SurveyorVFT Camera Dome System Wiring • 31
