Pelco
Function Ke
press Function Ke
press
Enter Menu
95, Preset Set (Program Label screen appears),
F2 Set Transmit Polarity
93, Preset Set (Program Label screen appears),
F2
Select/Store IO (Iris Open) Program Sectors
96, Preset Set (Program Label screen appears),
F2 then press Pan Auto to set sectors, Aux 2 and
3 to set mask.
Backup/Abort/Exit IC (Iris Close) Reset Dome
97, Preset Set (Program Label screen appears),
F2
Iris Open Iris Open- Controls Autoiris Levels Set AP limits
92, Preset Set (Program Label screen appears),
F2 then <2> Aux to set left limit and <3> Aux to
set right limit
Iris Close
Iris Close - Controls Autoiris Levels
Set Pan limits
90, Preset Set (Program Label screen appears),
F2 then <2> Aux to set left limit and <3> Aux to
set right limit
Focus Near
Focus Near
Diagnostic Screen
91, Preset Set (Program Label screen appears),
F2
Focus Far
Focus Far
Debug Screen
99, Preset Set (Program Label screen appears),
F2
Zoom Out
Zoom Wide
Preset Tours
The controller MPT9500 doesn't support Pelco
tours. Vicon's tours are accessible using presets
80-87 or the menu system. To store a tour, Enter
preset number, Preset Set , F2. To run tour use
Preset Go.
Zoom In
Zoom Tele
Auto Tour
Pelco calls these patterns; there are multiple
ways of programming. The keypad has default
shortcut keys. This maps to our preset 88. It will
not access preset 89. Press <1>, F1 to start
programming. Press <2>, F1 to stop
programming. Press <3>, F1 to run the tour.
Programming using the Vicon way allows access
to autotours 88 and 89. To program tour 88 enter
<88>, Preset Set, F2 to start programming. A
prompt appears to press Aux 1 to start
programming. When the pattern is complete
press Aux 1 again to stop programming. Then
press IO to store or IC to abort. The tour can also
be programmed thru the menu system.
Camera Off
Camera Off
Night Mode- Manual <6> Aux to engage. <6> F3 to disengage
Camera On
Camera On
Alarms Programmed through the menu system.
Autopan Pan Auto = On , Pan Man = Off Alarm Acknowledge
Enter any number from 1-9 and press "Alarm
Ack". The SurveyorVFT will acknowlede the
alarms in received order.
Autoiris No Control- Unit is always in autoiris.
Turbo (Set speed to
full) - (Pelco Feature) Turbo Button
Lens Speed
8, F1, enter 1 or 2 for low, 3 for med , 4 for high.
Zoom and focus speed are the same. Flip (Turn 180 degrees) 5,F1
Auxs
Supports only a latching relay. Press <1>, Aux
to engage. Press <1> , F3 to disengage
Peel (Sensormatic
Feature) Not Supported
Presets
Preset Store - 1 to 32 , 35 to 79 - Enter Preset
Number, Preset Set (Program Label screen
appears), F2 - No preset label editing. Can be
programmed through menu.
Preset Recall - Enter Preset Number, Preset Go
Camera Control
Including Adjust
V-Phase Menu system
XX134-01-00 Rev 205 SurveyorVFT Camera Dome System Competitive Protocols • 51
