Model Numbers
SVFT-C22CA, SVFT-P22CA, SVFT-W22CA SVFT-C22CA-C, SVFT-P22CA-C, SVFT-W22CA-C
Product Codes
8741-00, 8742-00, 8743-00 8741-01, 8742-01, 8743-01
Formats
Camera
Specifications
NTSC PAL
Type
Color Color
Optical Zoom
22X 22X
Digital Zoom
12X 12X
Total Zoom
264X 264X
Zoom Speed
OPTICAL wide/DIGITAL tele: 3.9 sec OPTICAL wide/DIGITAL tele: 3.9 sec
Image Device
1/4-inch interline transfer CCD 1/4-inch interline transfer CCD
Picture Elements
768(H) x 494 (V), 380,000 pixels 752(H) x 582 (V), 438,000 pixels
Scanning System
2:1 interlace, 525 lines 60 fields/sec 2:1 interlace, 625 lines 50 fields/sec
Sensitivity
0.2 fc (2 lux) at 40 IRE, f/1.6 0.2 fc (2 lux) at 40 IRE, f/1.6
Horizontal Resolution
470 TV lines 460 TV lines
S/N Ratio
More than 50 dB More than 50 dB
Synchronization
Internal/External (line lock on AC line) Internal/External (line lock on AC line)
Backlight
Compensation
ON/OFF ON/OFF
Iris Control
Automatic/Manual Automatic/Manual
Video Focus
Automatic/Manual; 1.0 m (tele ) - 0.01 m (wide) Automatic/Manual; 1.0 m (tele ) - 0.01 m (wide)
White Balance
Automatic/Manual; Red/Blue Gain Level Automatic/Manual; Red/Blue Gain Level
Shutter Speed
1/60 - 1/4000 sec 1/50 - 1/4000 sec
Input Voltage
9.0 –12 VDC 9.0 –12 VDC
Power Consumption
4.0 W max 4.0 W max
Dimensions H x W x L
2.4 x 2.0 x 3.5 in. (60 x 50 x 89.5 mm) 2.4 x 2.0 x 3.5 in. (60 x 50 x 89.5 mm)
Weight
0.5 lb (0.22 kg) 0.5 lb (0.22 kg)
Lens Specifications
Focal Length
4 - 88 mm 4 - 88 mm
Aperture max
f/1.6 f/1.6
Horizontal Angle of
View
47.3° wide, 2.2° tele 47.3° wide, 2.2° tele
Table 3: Camera/Lens Specifications (continued)
XX134-01-00 Rev 205 SurveyorVFT Camera Dome System Technical Information • 67
