MAINTENANCE
The following sections instruct on how to remove and replace internal
valve components. Care must be taken to avoid damage to parts during
removal and installation.
WARNING
Depressurizeanddrainthepipingsystem•
beforeattemptingtoremovethecoverplate
fromthevalve.
Failuretofollowthisinstructioncouldresult
inseriouspersonalinjuryand/orproperty
damage.
CAUTION
Anyactivitiesthatrequiretakingthe•
valveoutofservicemayeliminatethe
fireprotectionprovided.
Beforeservicingortestingthesystem,•
notifytheauthorityhavingjurisdiction.
Considerationofafirepatrolshouldbe•
givenintheaffectedareas.
Failuretofollowtheseinstructionscould
resultinseriouspersonalinjuryand/or
propertydamage.
REMOVINGANDREPLACINGTHECLAPPERSEAL
1. Perform steps 1 – 12 of the “Required Internal Inspection” section.
2. Remove the seal assembly bolt/bolt seal from the clapper seal.
3. Remove the seal-retaining ring.
CAUTION
DONOTprythesealwasheroutoftheclappersealfromthe•
innerhole.
Failuretofollowthisinstructioncoulddamagethesealwasher,
resultinginimproperclappersealingandvalveleakage.
4. Pry the edge of the seal washer from inside the clapper seal, as
shown above. DONOTPRYTHESEALWASHEROUTFROM
THEINNERHOLE.
5. Remove the seal washer from the clapper seal. Dry up any
moisture that is under the seal washer and on the clapper seal.
CAUTION
UseonlyVictaulic-suppliedreplacementparts.•
Failuretofollowthisinstructioncouldcauseimpropervalve
operation,resultinginpropertydamage.
I-769D_37
FireLockNXT™DelugeValve
SERIES 769
I-769DINSTALLATION,MAINTENANCE,ANDTESTINGMANUAL
www.victaulic.com
VICTAULIC IS A REGISTERED TRADEMARK OF VICTAULIC COMPANY. © 2007 VICTAULIC COMPANY. ALL RIGHTS RESERVED. PRINTED IN THE USA.
REV_D
