Videx 4000 Series Technical Manual

66250754-EN - V1.0 - 18/02/19
- 11 -
4000 Series GSM Audio Intercom - Technical Manual
4000 Series GSM Audio Intercom with Proximity
GSM4K AUDIO KITS
Additional GSM4K-n (ush) kit versions are available from 3 way kits up to 12 way kits: GSM4K-3 up to GSM4K-12. Each audio
kit comes with the appropriate Art.4810 GSM module, appropriate extension button module(s) and appropriate ush back box
depending on the GSM4K-n kit required (where n = the number of call buttons), refer to table below.
Additional GSM4K-nS (surface) kit versions are available from 3 way kits up to 12 way kits: GSM4K-3S to GSM4K-12S. Each audio
kit comes with the appropriate Art.4810 GSM module, appropriate extension button module(s) and appropriate surface back box
depending on the GSM4K-nS kit required (where n = the number of call buttons), refer to table below.
Kit No. Outdoor station composed of: Kit No. Outdoor station composed of:
FLUSH
GSM4K-3 1 Art.4810-0; 1 Art.4843; 1 Art.4852
SURFACE
GSM4K-3S 1 Art.4810-0; 1 Art.4843; 1 Art.4882
GSM4K-4 1 Art.4810-0; 1 Art.4844; 1 Art.4852 GSM4K-4S 1 Art.4810-0; 1 Art.4844; 1 Art.4882
GSM4K-5 1 Art.4810-0; 1 Art.4845; 1 Art.4852 GSM4K-5S 1 Art.4810-0; 1 Art.4845; 1 Art.4882
GSM4K-6 1 Art.4810-1; 1 Art.4845; 1 Art.4852 GSM4K-6S 1 Art.4810-1; 1 Art.4845; 1 Art.4882
GSM4K-7 1 Art.4810-2; 1 Art.4845; 1 Art.4852 GSM4K-7S 1 Art.4810-2; 1 Art.4845; 1 Art.4882
GSM4K-8 1 Art.4810-0; 1 Art.4843; 1 Art.4845; 1 Art.4853 GSM4K-8S 1 Art.4810-0; 1 Art.4843; 1 Art.4845; 1 Art.4883
GSM4K-9 1 Art.4810-0; 1 Art.4844; 1 Art.4845; 1 Art.4853 GSM4K-9S 1 Art.4810-0; 1 Art.4844; 1 Art.4845; 1 Art.4883
GSM4K-10 1 Art.4810-0; 2 Art.4845; 1 Art.4853 GSM4K-10S 1 Art.4810-0; 2 Art.4845; 1 Art.4883
GSM4K-11 1 Art.4810-1; 2 Art.4845; 1 Art.4853 GSM4K-11S 1 Art.4810-1; 2 Art.4845; 1 Art.4883
GSM4K-12 1 Art.4810-2; 2 Art.4845; 1 Art.4853 GSM4K-12S 1 Art.4810-2; 2 Art.4845; 1 Art.4883
GSM4KCR AUDIO KITS
Additional GSM4KCR-n (ush) kit versions are available from 3 way kits up to 12 way kits: GSM4KCR-3 up to GSM4KCR-12. Each
audio kit comes with the appropriate Art.4810 GSM module, appropriate extension button module(s), Art.4903 codelock module
and appropriate ush back box depending on the GSM4KCR-n kit required (where n = the number of call buttons), refer to table
below.
Additional GSM4KCR-nS (surface) kit versions are available from 3 way kits up to 12 way kits: GSM4KCR-3S to GSM4KCR-12S. Each
audio kit comes with the appropriate Art.4810 GSM module, appropriate extension button module(s), Art.4903 codelock module
and appropriate surface back box depending on the GSM4KCR-nS kit required (where n = the number of call buttons), refer to table
below.
Kit No. Outdoor station composed of: Kit No. Outdoor station composed of:
FLUSH
GSM4KCR-3 1 Art.4810-0; 1 Art.4843; 1 Art.4903; 1 Art.4853
SURFACE
GSM4KCR-3S 1 Art.4810-0; 1 Art.4843; 1 Art.4903; 1 Art.4883
GSM4KCR-4 1 Art.4810-0; 1 Art.4844; 1 Art.4903; 1 Art.4853 GSM4KCR-4S 1 Art.4810-0; 1 Art.4844; 1 Art.4903; 1 Art.4883
GSM4KCR-5 1 Art.4810-0; 1 Art.4845; 1 Art.4903; 1 Art.4853 GSM4KCR-5S 1 Art.4810-0; 1 Art.4845; 1 Art.4903; 1 Art.4883
GSM4KCR-6 1 Art.4810-1; 1 Art.4845; 1 Art.4903; 1 Art.4853 GSM4KCR-6S 1 Art.4810-1; 1 Art.4845; 1 Art.4903; 1 Art.4883
GSM4KCR-7 1 Art.4810-2; 1 Art.4845; 1 Art.4903; 1 Art.4853 GSM4KCR-7S 1 Art.4810-2; 1 Art.4845; 1 Art.4903; 1 Art.4883
GSM4KCR-8
1 Art.4810-0; 1 Art.4843; 1 Art.4845;
1 Art.4903; 2 Art.4852
GSM4KCR-8S
1 Art.4810-0; 1 Art.4843; 1 Art.4845;
1 Art.4903; 1 Art.4884
GSM4KCR-9
1 Art.4810-0; 1 Art.4844; 1 Art.4845;
1 Art.4903; 2 Art.4852
GSM4KCR-9S
1 Art.4810-0; 1 Art.4844; 1 Art.4845;
1 Art.4903; 1 Art.4884
GSM4KCR-10 1 Art.4810-0; 2 Art.4845; 1 Art.4903; 2 Art.4852 GSM4KCR-10S 1 Art.4810-0; 2 Art.4845; 1 Art.4903; 1 Art.4884
GSM4KCR-11 1 Art.4810-1; 2 Art.4845; 1 Art.4903; 2 Art.4852 GSM4KCR-11S 1 Art.4810-1; 2 Art.4845; 1 Art.4903; 1 Art.4884
GSM4KCR-12 1 Art.4810-2; 2 Art.4845; 1 Art.4903; 2 Art.4852 GSM4KCR-12S 1 Art.4810-2; 2 Art.4845; 1 Art.4903; 1 Art.4884
IMPORTANT NOTE: The GSM audio kits listed above work on a 2G network. For the 3G variant remember to sux the kit part
no. with /3G, e.g. GSM4K-4/3G, GSM4KCR-6S/3G etc.
All GSM audio kits are supplied with a HDR-15-12 12Vdc, 1.25A slim line power supply.
System Components and Available Versions

Videx 4000 Series Specifications

General

Series	4000 Series
Category	Intercom System
Material	Stainless Steel
Operating Voltage	12V DC
Housing Material	Stainless steel
Compatibility	Compatible with Videx audio and video internal units
