Videx 4000 Series Technical Manual

66250754-EN - V1.0 - 18/02/19
- 19 -
4000 Series GSM Audio Intercom - Technical Manual
4000 Series GSM Audio Intercom with Proximity
TERMINAL CONNECTIONS TECHNICAL SPECIFICATION
Connection Description Working voltage: 12V - 24Vac/dc +/- 10%
+ 12-24V AC or DC power input Current (standbay): 150mA
- 0V power input Current (operation): 150mA (max.)
PTE Switched 0V input to trigger relay Number of relays: 1x, C, NC and NO
C Relay common connection
3A @
24Vac⁄dc
max.
Relay current⁄voltage: 3A @ 24Vac/dc (max.)
NC Relay normally closed connection Push to exit inputs: 1x, PTE (switched 0V)
NO Relay normally open connection RS485 bus connections: 2x A, 2x B and - (GND)
B
RS485 bus terminal connections
RS485 termination: Yes, Jumper
A Networkable: via RS485 (up to 8 devices max.)
- RS485 ground connection Programming: Tens, units, store & delete buttons
B
RS485 bus terminal connections
(for unit ID & relay time only)
A
Working Temperature: -10 +50
o
C
Art. 4850R Technical Information

Videx 4000 Series Specifications

General

Series	4000 Series
Category	Intercom System
Material	Stainless Steel
Operating Voltage	12V DC
Housing Material	Stainless steel
Compatibility	Compatible with Videx audio and video internal units
