Initial Programming
All programming is carried out using the keypad. The programming menu is protected by an engineer’s code. The factory default
engineer’s code is ‘111111’ (6x1). This code can be changed to any 4 to 8 digit engineer’s code during the programming, but must
be dierent to the access codes used to gain entry. Follow the ow chart below to setup the access codes:
The red LED will illuminate to acknowledge the Art.4800 - Art.4800M is in
programming mode. If the red LED does not illuminate check the engineer’s code
is correct. If the engineer’s code has been changed from the factory default and
you do not know what it is then follow the factory default procedure on page 14.
Enter a new engineer’s
code or enter the same
engineer’s code again.
Then press ENTER.
Enter the access code
for relay 1.
Then press ENTER.
Enter a two digit relay 1
time from 00 - 99 seconds.
Then press ENTER.
Enter the default engineer’s
code ‘111111’.
Then press ENTER.
More codes?
Enter a two digit relay 2 / 3
time from 00 - 99 seconds.
Then press ENTER.
Enter the access code
for relay 2 / 3.
Then press ENTER.
Press ENTER twice to
exit programming
YES
NO
This new engineer’s code can be from 4 – 8 digits long and will not activate the
relays. It can only be used to enter programming mode. Please note that this new
engineer’s code will be needed to re-program the Art.4800 - Art.4800M relay codes
in the future.
This access code will be used to open the door/gate for relay 1. The code can be
from 4 – 8 digits long and must be dierent from the engineer’s code.
This is the time that relay 1 will activate for. It is a two digit number, for example
if relay 1 needs to activate for 5 seconds then enter ‘05’ followed by ENTER. ‘00’
will latch the relay when the access code is entered and require the access code
followed by CLEAR to unlatch.
This access code will be used to open the door/gate for relay 2/relay 3. The code
can be from 4 – 8 digits long and must be dierent from the engineer’s code and
dierent from the previous access codes.
This is the time that relay 2/relay 3 will activate for. It is a two digit number, for
example if relay 2/relay 3 needs to activate for 5 seconds then enter ‘05’ followed
by ENTER. ‘00’ will latch the relay when the access code is entered and require the
access code followed by CLEAR to unlatch.
The Art.4800 - Art.4800M codelock will play a melody and the red LED will switch
OFF to conrm all the settings are saved and exit from programming mode.
Melody
Melody
Melody
Melody
Melody
Melody
