4000 Series GSM Audio Intercom - Technical Manual
4000 Series GSM Audio Intercom with Proximity
2. The SIM holder is hinged and will open out to the left, see
Fig.34.
Fig. 34
3. Place the SIM card into the holder (it will only t one way, see Fig.35) and fold the holder back down, see Fig.36.
Fig. 35 Fig. 36
4. Slide the SIM holder back to the right until it ‘clicks’, see
Fig.37.
Fig. 37
5. Once the SIM is in place follow the initialisation process.
6. Check all the connections have been made correctly and then power up the system.
7. The GSM PRO intercom requires approximately 30 seconds too initialise properly. We recommend NOT sending SMS messages
or pressing buttons during this time. The busy LED will ash while initialising.
8. From power up; two short beeps will be heard and then following a short delay of approximately 15 seconds, a further short
beep will be heard. After approximately another 15 seconds another short beep will be heard (if you hear a dierent combination
of beeps in place of the last short single beep then you can nd the meaning of these beeps towards the back of this manual).
9. Once the GSM PRO module has initialised (the busy LED has stopped ashing) you can begin programming.
POWER UP INITIALISATION SEQUENCE
• 2 short beeps.
• Approx. 15 seconds delay.
• 1 short beep.
• Approx. 15 seconds delay.
• 1 short beep.
• Wait for busy LED to stop ashing.
• System is ready.
