PAGE 12 of 80 VX2200 TECHNICAL MANUAL VER1.4
NOTES:-
SET SPEECH PLAYBACK
(0 to 2)
0=NO 1=ST 2=CMB
SPEECH BOARD
0=NO 1=ST 2=CMB
SPEECH BOARD
SELECT 0
-
5
CONTINUED FROM PREVIOUS PAGE
MASTER/SLAVE SETTING
(0 = SLAVE, 1=MASTER)
MASTER : NOT
1 = YES
MASTER : YES
0 = NOT
SELECT 0
-
5
(
*
)
NOTE 2-3
AUTOMATIC FLAT TEST
(1 or ENTER)
1 = TEST FLAT
“ENTER” = END
TEST FLAT 101
ID PG 1-1 OK
SELECT 0 or 1
SYSTEM READY TO USE
ENTER FLAT NR.
Å- SEARCH -Æ
ENTER FLAT
NUMBER
SELECT 1 or ENTER
(
*
)
NOTE 2-3
(
*
)
NOTE 1
PRESS CLEAR BUTTON TO CANCEL THE LOCATION
(
*
)
NOTE 2
DURING THE PROGRAMMING TO CONFIRM THE STORED DATA, PRESS
ENTER TWICE
(
*
)
NOTE 3
TO PROGRAM AS SLAVE ONLY IF THERE IS ANOTHER ENTRANCE
PROGRAMMED AS MASTER ON THE SAME BUS
(
*
)
NOTE 4
DOOR PANEL SOFTWARE VERSION 5.0 or later: LOCATIONS 0 & 999
ARE RESERVED FOR EDITING THE DISPLAY LOGOS.
EARLIER SOFTWARE: LOCATIONS 0 & 255 ARE RESERVED FOR
EDITING THE DISPLAY LOGOS.
(
*
)
NOTE 5
THIS SCREEN WILL ONLY APPEAR IF THE DOOR PANEL IS IN MAIN
MODE. POWER UP WITH 0 HELD IN FOR MAIN MODE, POWER UP
WITH ENTER HELD IN FOR LOCAL MODE
(
*
)
NOTE 6
THIS SCREEN WILL ONLY APPEAR ON NAME SCROLL FACILITY DOOR
PANELS. THE FOLLOWING KEYS ON THE KEYPAD DOUBLE UP AS
LETTERS WHEN ENTERING NAMES:-
Å or A = Back CALL or B = Accept Æ or C = Forward
1 = .& 2 = ABC 3 = DEF
4 = GHI 5 = JKL 6 = MNO
7 = PQRS 8 = TUV 9 = WXYZ
0 = +-*/
