PAGE 6 of 80 VX2200 TECHNICAL MANUAL VER1.4
Videomonitors (5478, 5478/CA, 5478/CR, VR5478)
5000 Series videomonitors with coax and non coax video options. Including colour video, timed privacy
facility, half duplex handsfree speech (Optional handset kit or simplex speech option) and spare service
buttons. A flush mounting kit is also available for these monitors which are also available in white, silver or
carbon fibre affect finishes. Also available in vandal resistant flush.
Extension sounder (512D)
Extension Sounder in a white plastic wall mount box. Connects directly to the 2 wire bus.
Extension relay (512DR)
As the 512D but with a dry contact relay (24V 100mA) instead of the sounder.
Non-coax camera module (830/NC, 830C/NC)
800 series camera module with infrared illumination. “No coax” required. (Colour camera 830C/NC has white
LED’s as oppose to IR LED’s)
Coax camera (830, 830C)
As above but for coax video systems. Use 830NC /830NC/C for non-coax camera.
Coax/Non-coax camera (4830, 4830C)
A 4000 series camera with both coax and non-coax connections. Available in mono or colour.
1A DIN Rail Power Supply Unit (521B)
For audio systems with battery back-up facility, 230Vac / 13Vdc/ac – 1 Amp.
Video Power Supply (893N1)
For video systems, 230 Vac / 20Vdc – 1 A peak current (0.8 A continuous current).
Audio control cabinet (SP400, SP405)
Lockable control cabinet for one door (SP400) and up to 4 doors (SP405) audio systems. Includes a
BST/GMT time clock, PSU and facility for a backup battery.
Video control cabinet (SP410, SP415)
Lockable control cabinet for one door (SP410) and up to 4 doors (SP415) video systems. Includes a
BST/GMT time clock, PSU’s for both audio and video, video switching PCB (Multipe door cabinet only) and
facility for a backup battery (Audio backup only).
Non-Coax Video Distributor (316, 316N)
Video splitter for no-coax video systems, One required for every four videophones.
Coax Video Distributor (894, 894N)
As above but for coax video systems.
