161
5.
A
4.
4x
TX 25
Fig. 110
Note
Torque for the screws: 1.8 +0.5 Nm
A
Evaporator
Removing the rear casing
1. Remove side casing, right: See Fig. 104. 2. Remove top cover: See Fig. 106.
Outdoor unit maintenance
Removing the outer casing (cont.)
6222080
Maintenance
