160
8.
F
TX 25
Fig. 109
Note
Torque for the screws: 1.8 +0.5 Nm
F
Front panel
Removing the left-hand side casing
1. Remove side casing, right: See Fig. 104.
2. Remove top cover: See Fig. 106.
3. Remove fan grilles and reinforcing strut: See
Fig. 107.
Outdoor unit maintenance
Removing the outer casing (cont.)
6222080
Maintenance
