24
Handling using transport aids
Danger
If the transport aids are damaged, the outdoor
unit may fall. This can lead to refrigerant circuit
damage. Should damage to the refrigerant cir-
cuit occur, there is the risk of explosion or
asphyxiation.
■
Check transport aids for damage before han-
dling.
■
Use the carrying aid only once to transport
the outdoor unit.
■
Do not use the transport aids when transport-
ing by crane.
■
Take note of the weight of the outdoor unit:
See chapter "Specification".
The transport aids are each found in the mounting rail
under the outdoor unit:
■
The outdoor unit with 1 fan has only 1 transport aid
on the right-hand mounting rail.
■
Due to the uneven weight distribution, there are 4
transport aids attached to the right-hand mounting
rail for outdoor units with 2 fans: See Fig. 7.
Fig. 7
A
Transport aid
Siting the outdoor unit
Transporting the outdoor unit (cont.)
6222080
Installation
