Subject to the components connected and the settings
made, you can scan current temperatures and operat-
ing conditions.
Information in the main menu is split into groups:
■
"General"
■
"Heating circuit 1"
■
"Heating circuit 2"
■
"Heating circuit 3"
■
"DHW"
■
"Solar"
■
"Ventilation"
■
"Service contact details"
■
"Reset data"
Note
If heating circuits have been named (see chapter
"Naming heating circuits") the assigned name is dis-
played.
Detailed options for data scanning on individual groups
can be found in chapter "Data call-up options".
Tap the following on-screen buttons:
1. "Menu"/" "
2. "Information"
Temperature profile of the DHW cylinder
Subject to the type of DHW cylinder, the temperature
curve is displayed graphically.
The curves show the temperature profile at the individ-
ual test points in the DHW cylinder.
Tap the following on-screen buttons:
1. "Menu"/" "
2. "Information"
3. "DHW"
4. "Cylinder bar chart"/"Overview, DHW cylinder"
5. Required period
You can call up the following periods:
■
24 hours
■
7 days
■
30 days
Temperature stratification in the DHW cylinder
Subject to the type of DHW cylinder, the temperature
stratification is displayed graphically.
Tap the following on-screen buttons:
1. "Menu"/
2. "Information"
3. "DHW"
4. "Cylinder, temperature stratification"
5. Required period
You can call up the following periods:
■
24 hours
■
7 days
■
30 days
Calling up the solar energy yield in conjunction with solar thermal systems
Only in conjunction with the solar control module,
type SM1. When connected to a Vitosolic solar control
unit, you can call up the solar energy yield on the
Vitosolic.
Tap the following on-screen buttons:
1. "Menu"/
2. "Information"
3. "Solar"/"Solar energy"
4. "Solar energy bar chart"/"Overview, solar
energy"
5. "Required period (if available)"
Note
For further options on calling up data, e.g. the solar cir-
cuit pump hours run, see the extended menu under
"Information" in the "Solar" group.
Calling up information
Scanning information
