49
Outside temperature sensor
A
1 2
1 2 3 4
B
B3
ATS B42/
B10
A
Outside temperature sensor
B
Junction box
Installation:
■ North or north-westerly wall, 2 to
2.5 m above ground level; in multi
storey buildings, in the upper half of
the second floor
■ Not above windows, doors or vents
■ Not immediately below balconies or
gutters
■ Never render over
Installation sequence
Terminal connections
(cont.)
5618 294 GB
Installation
