Insulation
15
Mounting Insulation (Continued)
Note: Burner cable
is included in the insulation carton.
6. Mount front panel on top of boiler as
shown. Secure with supplied hex
nuts.
7. Open combustion chamber door.
8. Thread smaller plug of burner cable
through opening on lower right of
cover panel (if s upplied).
9. Lay smaller plug of burner cable on
top of boiler.
5285 838 v2.1
M10
M10
6.
8.
9.
7.
Cover panel, if supplied
To Next Page
