Viessmann VR2 Series - Mounting Insulation (Continued)

Insulation
25
Mounting Insulation (Continued)
1. Position lower front panel on base
panel and fasten with two 3.9 x 9.5
sheet metal screws.
2. Close combustion chamber door.
3. Position side panels with hooks in the
opening of the rear panel and on the
latches of the base panel. Lift and
hook into front and rear panel.
5285 838 v2.1
1.
3.
2.
Cover panel, if supplied
