ViewSonic myViewBoard Sens User Manual

30
Specicaons
Camera
Wide Camera Sensor Sony IMX317 1/2.5", 3840x2160 (1.62um), D=7.14, CRA = 4.5° WDR
Scanning Mode Progressive
Lens Fix iris/focus 1/2.5" F2.0± 5%
EFL(mm) 3.16± 5% mm
FOV (degree) FOV-D = 146.6° ± 5°
FOV-H = 123.1° ± 5°
FOV-V = 65.1° ± 5°
Lens Structure 2G3P
Image Circle Max ø7.28mm
Optical Distortion -66.3% @ D=7.14mm
Relative Illumination 35% @ D=7.14mm
Chief Ray Angle 16.1° @ D=7.14mm
TVL Center : 1450TVL Focus &Test at 5M
0.7F : 1100TVL Focus &Test at 5M
Focus range 2m~6.5m (face must be no smaller than 80x80 pixel)
Tele Camera Sensor Sony IMX317 1/2.5", 3840x2160 (1.62um), D=7.14, CRA = 4.5° WDR
Scanning Mode Progressive
Lens Fix iris/focus 1/2.3" F2.0± 5%
EFL(mm) 7.35± 5%mm
FOV (degree) FOV-D = 58.4° ± 5°
FOV-H = 50.2° ± 5°
FOV-V = 27.5° ± 5°
Lens Structure 2G3P
Image Circle Max ø7.5mm
Optical Distortion -13.69% @ D=7.2mm
Relative Illumination 40% @ D=7.2mm
Chief Ray Angle 15.9° @ D=7.2mm
TVL Center : 1450TVL Focus &Test at 9M
0.7F : 1100TVL Focus &Test at 9M
Focus range 6.4m~10m (face must be no smaller than 80x80 pixel)
Processor
ASIC NT96685(Novatek), build in 4Gb DDR
VPU MA2485(Intel), build in 4Gb DDR
Memory SPI NAND Flash 4Gb
PMIC PMIC
Audio Codec Audio Codec (Build in 2ch EQ,DRC for internal Mic, bypass for
external plug-in)
Sensors
Humidity/Temperature
sensor
Temperature : Measurement Range :-10~60°C
Accuracy : 5~60°C: ±3°C (At 1m/s air flow)
-10~5°C: ±3°C (At 1m/s air flow)
Humidity: Measurement Range :0~99%RH
Accuracy:20~80%RH: ±5%RH
Other RH: ±7%RH
Light level sensor Measurement Range :0~20K Lux Accuracy:±10%
Environment color
Temperature sensor
D65 => 6500K+/-500K
TL84 => 4100+/-500K
IncA => 2856K+/-500K
Horizon => 2300K+-500K
Color temperature sensor:2000~10000k Accuracy:±20 %
PIR sensor Detection Range : 2 Meter(H=100° ±10° / V=60° )
Sensitivity level: L / M / H
